Single Impeller Centrifugal Water Pump 8700 GPH – 3HP – CTX330/2.2 – SS304 – 208/230V, 3P

Print Product Page

Single Impeller Centrifugal Water Pump – SS304, 3 HP, 208/230V, 3-Phase
Stainless steel centrifugal water pump designed for domestic, agricultural, and industrial water transfer applications. Suitable for sprinkler systems, flood irrigation, pressure boosting, and water distribution from storage tanks.

Applications
  • Domestic water transfer
  • Agricultural irrigation and sprinkler systems
  • Flood irrigation and gardening systems
  • Pressure boosting from tanks and water supply systems
  • Industrial and general water circulation applications

Operating Conditions
  • Liquid temperature up to 95°F for residential use
  • Maximum liquid temperature up to 194°F for other applications
  • Maximum ambient temperature: 104°F
  • Maximum suction lift: 23 ft

Motor
  • Two-pole induction motor, 3450 RPM
  • Insulation Class F
  • Protection rating: IP55
  • 208/230V, 3-Phase power supply

Materials
  • Pump body: Stainless Steel AISI 304
  • Motor support: Aluminum
  • Impeller: Stainless Steel AISI 304
  • Shaft with rotor: Stainless Steel AISI 304
  • Mechanical seal: Silicon / Graphite / EPDM

Made in Italy

Made in Italy

UNIT PRICE

$978.99

In Stock · Ships from Miami, FL
Get it fast: typically ships in 0–2 business days

🎄Christmas Sale Is Live

Buy 2 Get 5% · Buy 3 Get 8% · Buy 4+ Get 10% | applies automatically

See Why Thousands of Customers Trust Pump Supermarket

Take a quick look inside our Miami warehouse and daciscover the people, products, and expertise behind every order we ship.

✔ 4,000+ Products in Stock ✔ Fast Nationwide Shipping ✔ Expert Technical Support ✔ Trusted by Thousands of Customers

Description

More Details

Model CTX330/2.2
Brand SPERONI
Manufacturer’s Warranty 1 year
Ship Weight 47 lbs
Port Size (in.)  2″ –  1″-1/4
Flow (GPH) 8700
HP 3
Voltage 230V – Three Phase
Amps 5
Max. Total Head (ft.) 78
Max. Suction Lift (ft.) 20
Max. PSI 33.35
Suction Port (in.) 2″
Discharge Port (in.) 1″-1/4
Self-Priming No
Dimensions L x W x H (in.) 19 x 9 x 11
Product Weight (lbs.) 47 lbs

Additional information

Weight 54 lbs
Dimensions 19 × 9 × 11 in
