Description
Design Engineering
- Oil Bath Motor (Biodegradable and Dielectric) for Colling and Bearing Lubrication.
- Permissible Height of Water: 32.8 ft.
- Protection Class IP 68.
- Class “F” Insulation.
- By Pass Section: 0.4″.
- Max. Pumped Liquid Temperature 95°F .
- Single Phase: 230V/60Hz with built in thermal protection.
- Cable Length: 32.8 ft. H05VV-F.
Performance Curve
| Model | Voltage | HP | P1 Max. | Ampere | Capacitor | Capacity | |||||||||||
| 60Hz | Kw | A | μF | VC | Gal/Min | 0 | 13.2 | 26.4 | 39.6 | 66 | 79.3 | 125.5 | 141 | 184.9 | 220.1 | ||
| JURBO LG 250 | 1 x 230V | 3 | 2.2 | 14.5 | 50 | 450 | Ft. | 78.7 | 72.2 | 65.6 | 62.3 | 49.2 | 42.7 | 19.7 | 6.6 | – | – |
Dimensions
| Dimensions (inch) | Cable Length | Weight | ||
| A | B | C | Ft. | Lb |
| 2 | 9.4 | 22.8 | 32.8 | 99 |
Parts List and Materials
