Description
Operating Conditions
- Max working pressure: 145 PSI.
- Liquid temperature up to 194°F.
- Ambient temperature up to 104°F.
- Total suction lift up to 23 ft.
- Continuous duty.
Motor
- Two-Pole induction motor (n = 3450 min-1).
- Insulation Class F.
- Protection IP 44.
Materials
- Pump Body: Stainless Steel.
- Motor Support: Stainless Steel.
- Impellers: Stainless Steel.
- Diffuser: Stainless Steel.
- Pump Casing: Stainless Steel.
- Shaft with rotor: Stainless Steel.
- Mechanical seal: Graphite.
Performance Curve
| Type | Motor | Pump | |||||||||||||||
| Nominal Power (P1) | Input Power (P2) | Volt | Phase | Ampere | Q = Capacity | ||||||||||||
| HP | KW | KW | V | PH | A | Gal/Min | 8.8 | 11 | 13.2 | 15.4 | 17.6 | 22 | 26.4 | 30.8 | 35.2 | 39.6 | |
| RSXM 4-3 | 1.5 | 1.1 | 1.4 | 230V | 1 | 6.3 | Ft. | 128 | 121.4 | 118.1 | 111.5 | 108.3 | 101.7 | 91.9 | 75.5 | 59.1 | – |
Dimensions
| Size (inch) | Weight (lbs.) | ||||||||||
| A | B | C | D | E | F | H | H1 | I | DNA | DNM | |
| 6.3 | 5.1 | 15.6 | 6.7 | 4.3 | 0.4 | 9.1 | 4.3 | 7.2 | 1.25 | 1 | 37.4 |
