Description

Description & Features

EH pumps are designed in accordance with ISO 2858 standard while the performance even better than ISO 2858. Pumps have superior hydraulic design. by which  significantly higher efficiencies are achieved for less power consumption.
The now rates are 1.6 times and the heard 125 Urnes of their correspondent sizes in ISO 2858 standard.
Pump performance can be changed by impeller trimming. There are 4 sizes of shafts and 4 sizes of bearing housing among the whole series, and many of the parts such as shaft, shall sleeve, shaft seal and impeller nut of one pump are interchangeable with other pumps of the same bearing housing. Back pull-out design and driven by motor or other driving device through flexible coupling, very easy and convenient install and  maintain.

EA Performance Table – EH80-50-200 ~ 60Hz – 3500 rpm

EA Performance Table – EH80-50-200 ~ 60Hz – 1750 rpm

IS02858 END Suction Pump Performance Curve EH Series 60HZ – 3500 rpm

IS02858 END Suction Pump Performance Curve EH Series 60HZ – 1750 rpm

Applications

• Water supply and drainage
• HVAC and Cooling Tower
• Fire Protection and Fire Fighting
• Marine-Ballasting & Bilge
• Booster and Pressurization Set
• Irrigation and agriculture
• Water supply and drainage

Operating Data

• Flowrate: Max.1200 m’lh
• Head: Max. 160m
• Discharge Diameter (inches): 1.26-8
• Working Pressure(Mpa): 1.6-2.4
• Speed(r/min): 1750/3500(60Hz)

Material: Cast Iron

Structure & List of Parts

EH Dimension List
