• Watertight cable entry prevents water incursion from the capillary wicking.
• Multi-Direction Discharge can be changed between vertical and horizontal ways.
• Slim line design allows access into limited space.
• Double housing forms a water jacket to greatly cool the motor.
• A thermal protector is used on the motor to protect against overheating and dry-run.
• Air filled motor housed in a watertight casing, conforms to Class F insulation.
• C3 Ball Bearings and Hardened SS Shaft enhance stability during operation.
• Mechanical Sic Seal in lower side provides extra protection against leakage and dry-run.
• A Lip Seal works as an extra protection for mechanical seal from wear.
• PU Impeller is adopted for easy maintenance.
• Food Grade Lubricant helps minimizing environmental impacts.
