Description

TECHNICAL DATA

• Operating Range: capacity up to 35 gpm; head up to 218 ft (94 psi)

• Liquid quality requirements: clean, free from solids or abrasive substances, non-viscous, non-aggressive, non-crystallized, chemically neutral, close to the characteristics of water
• Liquid temperature Range:from 32°F to +95°F for domestic use for other use: from 32°F to +104°F

• Maximum Suction depth: 29 ft
• Maximum ambient temp. 122°F
• Maximum operating pressure: 94 psi
• Installation: fixed or portable in a horizontal position
• Power Supply:  230v 60Hz Single Phase

CONSTRUCTIONAL FEATURES OF THE PUMP

• Cast-iron motor frame and pump body.
• Impeller, diffuser, venturi tube and sand filter in technopolymer Twin impeller
• Stainless steel shim washers.
• Carbon/ceramic mechanical seals.

CONSTRUCTIONAL FEATURES OF THE MOTOR

• Asynchronous type, closed, with external air cooling.
• Rotor mounted on oversized greased-for-life ball bearings, to guarantee low noise and long life.
• Incorporated thermo-amperometric protection and permanently inserted condenser in the single phase version.
• It is recommended to use overload protection for three phase motor protection, in compliance with current legislation. Manufactured pursuant to CEI 2-3 and CEI 61-69 (EN 60335-2-41).

APPLICATIONS

• Self priming centrifugal pump with optimal liquid aspiration even in the presence of air bubbles.
• Suitable for pumping water with low levels of sandy impurities.
• Especially used in domestic water supply installations.
• Suitable for small farms and gardening, small scale industrial services and where self priming is necessary.

Pump Performance and dimensions
