Description

Applications:

✅ Residential Homes – Improves water pressure for showers, faucets, and appliances
✅ Irrigation Systems – Ensures stable pressure for garden and agricultural watering
✅ Commercial Buildings – Ideal for offices, small hotels, and apartment complexes
✅ Light Industrial Use – Provides consistent pressure for process water applications
✅ Rainwater Harvesting – Boosts stored water for efficient distribution

Key Features:

✔️ Fully Integrated System – Includes pump, pressure tank, and digital controller
✔️ Automatic Pressure Control – EPR pump controller ensures seamless operation
✔️ Energy-Efficient – Reduces pump cycling, extending pump lifespan
✔️ Compact & Easy to Install – Pre-assembled system for quick setup
✔️ Durable & Reliable – Built for long-term performance in various environments
✔️ Adjustable Output Pressure – Customizable settings for different applications
✔️ IP65 Rated Digital Switch – Water-resistant and suitable for harsh conditions

This booster system is perfect for anyone looking for reliable water pressure with easy installation and digital control for optimized performance.

MADE IN ITALY

Controller Brand: COELBO

MADE IN SPAIN

OPERATING CONDITIONS:

• – Liquid temperature up to 95°F (for home use according to EN 60335-2-41)
• – Temperature max. liquid: 95°F (for other uses)
• – Ambient temperature up to 104°F
• – Total suction lift up to 26.2 ft.

MOTOR

• – Single-phase 110/230V-60Hz
• – Insulation Class F
• – Protection IP 44

MATERIALS

• – Pump body: Stainless Steel 304
• – Motor Support: Aluminum
• – Impeller: Noryl
• – Diffuser: Noryl
• – Pump flange: Stainless Steel 304
• – Shaft with rotor: Stainless Steel 304
• – Mechanical seal: Ceramic/Graphite/NBR

More Details:

Pump driver with adjustable outlet pressure. Constant pressure.

EPR is a compact device for automatic control and protection of electric pumps up to 2,2 kW (3 HP), multi-voltage (110-230 V) and equipped with an innovative outlet pressure reducing/regulating system.
Therefore, in addition to the typical characteristics of traditional electronic pump controllers: integrated non-return valve, accumulation diaphragm, pressure gauge, dry-running protection, automatic reset, it allows to adjust and stabilize the outlet pressure, avoiding overloads, water hammer and, ultimately, improving end user comfort.

Made in Spain

Pump driver with adjustable outlet pressure. Constant pressure.
EPR is a compact device for automatic control and protection of electric pumps up to 2,2 kW (3 HP), multi-voltage (110-230 V) and equipped with an innovative outlet pressure reducing/regulating system.
Therefore, in addition to the typical characteristics of traditional electronic pump controllers: integrated non-return valve, accumulation diaphragm, pressure gauge, dry-running protection, automatic reset,it allows to adjust and stabilize the outlet pressure, avoiding overloads, water hammer and, ultimately, improving end user comfort..

OPERATING CHARACTERISTICS

– Power relay to manage electric pumps up to 2,2 kW (3 HP).
– Multi-voltage power supply: 110-230 V.
– Manual regulation of the constant outlet pressure with integrated adjusting tool.
– Outlet pressure indicator with pointer.
– Auto-setting of the start pressure linked to the outlet pressure.
– Dual scale integrated pressure gauge (bar/psi).
– Integrated protection system which stops the pump in case of dry-running operation.
– APR function (Anti-blocking periodic routine). After 3 days of inactivity, the device starts the pump for 10 seconds in order to avoid rotor-locking.
– ART function (Automatic Reset Test). If the device has been stopped due to the action of the safety system against dry run operation, this function tries to connect the pump, with a programmed periodicity, because the water supply could have been restored.
– Control panel:
– Yellow led light (POWER).
– Green led light (PUMP ON).
– Red led light (ALARM).
– Green led light (FLOW)
– Tactile push button for manual start.
– Integrated reserve against leaks in the installation and non-return valve.
– Inlet and outlet hydraulic threads: NPT 1”
