Description
Characteristics
- 2-pole motor with high speed rotation achieves the extra high-head water carrying.
- The impeller and its suction cover were made of the high chromium and specially treated, so as to long the workability.
- The Double mechanical seal is of silicon carbide made ensure the super durability.
- Top discharge for motor cooling function.
Applications
- Construction: Excavation, sump, ditch, tunnel, any foundation work & storm water removal.
- Factories: Waste water removal, sump pit, manhole, basement, emergency water removal & industrial processing water.
- Buildings: Sump pit, plumbing, manhole, elevator pit, emergency & storm water removal.
- Utilities: Excavation, sump, manhole, trench, sewage tunnel & storm water removal.
- Mining: Pit, quarry, excavation, tunnel & storm water removal.
- Home: Cellar, sump pit, plumbing, fountain & swimming pool cleaning.
- Farming: Irrigation & fire protection.
- Marine: Bilge, fire fighting & wash-down.
Performance Curve
| Type | Motor | Pump | |||||||
| Power | Phase | Volt | Pump Outlet Discharge | Max. Head | Max. Flow | Solid Passage | |||
| HP | KW | PH | V | Inch | Mm | Ft | Gal/Min | Inch | |
| GKT-732H | 7.5 | 5.5 | 3 | 460V | 3 | 80 | 91.9 | 317 | 2 x 0.4 |
Dimensions
| Size (inch) | Weight (lbs.) | ||
| A | B | C | |
| 10.9 | 5 | 28 | 169.4 |
Parts and Materials
