Free Shipping
2HP Submersible Motor 30GPM max Deep Well Water Pump 3Wire , 208-230V , 1P , 4″ – 436ft max with Splice kit
Gol Pumps’ Encapsulated-resin filled motor is developed with market expectation to meet the robust construction and stringent requirement, which is for 4” or larger well. The motor is 100% tested before shipment.
Pump Spec
- Max Head(ft): 736
- Max Flow(Gpm): 30
- Discharge: 1 1/4″
- HP: 2
- Pump Material: Noryl
- Pump Model: ST 1814
Product Advantages
- Hermetically sealed stator, anti-track, stator resin filled prevent motor burn out.
- High efficiency provides operation cost savings Thrust pad.
- Copper wiring.
- Pressure equalizing diaphragm.
- Removable lead connector.
- Control boxes available for single phase motor Standard NEMA mounting dimensions.
Technical Specifications
- Upper bracket: Cataphoresis treated cast iron plus SS304 cover cap.
- Max. Immersion depth: 985 ft.
- Protection: IP68.
- Nos. of start per hour: max 20 at regular intervals.
- Sand slinger and lip seal.
- Insulation: Class F.
- Rated ambient temperature: 86°F with min.
- Cooling flow 0.08 m/s of water flow speed.
- Standard installation position: vertical and horizontal.
*(Includes wire splice kit)
